Supporting OpenJFX 11 from JDK11 onwards in e(fx)clipse

So starting with JDK-11 OpenJFX is not part of any downloadable distribution. As JavaFX is designed to run on the module-path (and tested only there) you have 2 options to run JavaFX inside OSGi:
* You create your own JDK-Distribution using jlink
* You launch the VM you want to use JavaFX adding the JavaFX-Modules

While the 2nd solution is doable for RCP-Applications it is less than a nice one, and for integrating into external frameworks (like the Eclipse IDE) it is not possible at all. So we need a different solution to satisfy both usecases.

The solution to this problem is that e(fx)clipse installs a classloader hook using the Equinox AdapterHook-Framework (you can do crazy stuff with that) and on the fly spins up a new Java-Module-Layer containing all the JavaFX-Modules and uses the classloader from the Module-Layer to load the JavaFX-Classes.

With this strategy you can supply the JavaFX-Modules (including the native bits) required for your application to run as part of your p2-repository.

This entry was posted in Uncategorized. Bookmark the permalink.

6 Responses to Supporting OpenJFX 11 from JDK11 onwards in e(fx)clipse

  1. Christoph Keimel says:


  2. Pingback: JavaFX links of the week, August 6 | JavaFX News, Demos and Insight // FX Experience

  3. Marcelo says:

    I hope this is the last annoying change you need to tackle Tom, but with Oracle you never know…
    Will this approach also work with Maven based projects?

  4. ebousse says:

    Hi! Is there a tutorial somewhere that explains how to build an RCP application that has OpenJFX views, and to be able to run this RCP application for instance with a basic JRE from OpenJDK 11 ?
